- TitleGeneral arrangement drawing no 46057
- ReferenceYA1966.24/3/21/C/24/7257
- Production date1890 - 1890
- Scope and ContentGeneral arrangement drawing for order 7257, which comprised of four '2-4-2' rack locomotives for the Transandine Railway, Chile Progressive numbers 3171-3174
- Level of descriptionITEM
- Repository nameScience and Industry Museum
- Subject
- Conditions governing accessOpen access.
- Conditions governing ReproductionCopies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
