Title
General arrangement drawing no 45421
Reference
YA1966.24/3/21/C/24/7251
Production date
1889 - 1889

Creator

Mellor, -Biography Biography
Active c1884-c1899, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 7251, which comprised of four '2-6-0' locomotives for the Algeciras (Gibraltar) Railway Co Ltd Progressive numbers 3166-3169
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Algeciras Gibraltar Railway Company Biography Biography
The Algeciras Gibraltar Railway Company was formed by British businessmen to build the Algeciras-Bobadilla railway line between Algeciras and Bobadilla, Antequera. The railway was built for the benefit of British officers stationed in Gibraltar wanting to travel to Spain and the rest of Europe.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 21 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/24 Engineering drawings for orders recorded in Order book No 29, numbers 7168-7273
- ITEMYA1966.24/3/21/C/24/7251 General arrangement drawing no 45421
