Title
General arrangement drawing no 38338
Reference
YA1966.24/3/21/C/18/6438
Production date
1885 - 1885

Creator

Jamieson, -Biography Biography
Active 1885, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 6438, which comprised of 20 '0-6-0' locomotives for the Hull & Barnsley Railway Progressive numbers 2489-2508
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Hull & Barnsley Railway Co Biography Biography
The Hull Barnsley & West Riding Junction Railway and Dock Company changed its name to the Hull & Barnsley Railway in 1905. It amalgamated with the North Eastern Railway Company in mid-1922, very shortly before Grouping. Most of the railway has now been abandoned save for a short section serving Drax power station and the high-level route around Hull.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Related object

General arrangement drawing no 37009 Notes Notes

Hierarchy browser

contains 14 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/18 Engineering drawings for orders recorded in Order Book No 22, numbers 6428-6560
- ITEMYA1966.24/3/21/C/18/6438 General arrangement drawing no 38338
