Title
General arrangement drawing no 18780
Reference
YA1966.24/3/21/C/8/2804
Production date
1872 - 1872

Creator

Glib, J Biography Biography
Active 1872, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 2804, which comprised of one '0-4-2' locomotive for the Maryport & Carlisle Railway Progressive number 1144.
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Maryport & Carlisle Railway Co Biography Biography
Railway incorporated in 1837 to connect Carlisle and Maryport. George Stephenson was the engineer of the line, which opened fully on February 10, 1845. It became part of the London, Midland and Scottish Railway in 1923.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 19 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/8 Engineering drawings for orders recorded in Order Book No 10, numbers 2772-2997
- ITEMYA1966.24/3/21/C/8/2804 General arrangement drawing no 18780
