Title
General arrangement drawing no 2538
Reference
YA1966.24/3/21/C/1/167/1
Production date
1857 - 1857

Creator

Jaeger, -Biography Biography
Draughtsman for Beyer, Peacock & Co. Ltd, known to have been active 1855-1859

Scope and Content
General arrangement drawing for order 167, which comprised of one '2-4-0' locomotive for the Belgian Government Railway. Progressive number 54.
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Belgian Government Railway Biography Biography
The Belgian State Railways was the original state-owned railway of Belgium, established in 1834. The first line, between Brussels and Mechelen opened on 1835 and was the first steam powered public railway in continental Europe. Its assets and operations were transferred to the newly created National Railway Company of Belgium in September 1926.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
