- TitleGeneral arrangement drawing no 46644
- ReferenceYA1966.24/3/21/C/25/7292
- Production date1890 - 1890
- Scope and ContentGeneral arrangement drawing for order 7292, which comprised of eight '4-4-0' locomotives for the Royal Portuguese Railway Progressive numbers 3239-3246
- Level of descriptionITEM
- Repository nameScience and Industry Museum
- Subject
- Conditions governing accessOpen access.
- Conditions governing ReproductionCopies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
