Title
General arrangement drawing no 46481
Reference
YA1966.24/3/21/C/25/7290
Production date
1895 - 1895

Creator

Shepherd, -Biography Biography
Active c1879-1896, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 7290, which comprised of five '4-4-0' locomotives for the Buenos Aires & Rosario Railway, Argentina Progressive numbers 3234-3238
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Buenos Aires & Rosario Railway Biography Biography
British owned railway operating in Argentina, opening in 1874. The company merged with the Central Argentine Railway in 1902.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
