Title
General arrangement drawing no 44453
Reference
YA1966.24/3/21/C/23/7150
Production date
1889 - 1889

Creator

Gomm, A. H.Biography Biography
Active c1887-c1889, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 7150, which comprised of two '2-6-0' locomotives for the Argentine Great Western Railway Progressive numbers 3036-3037
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Argentine Great Western Railway Biography Biography
British-owned railway company, founded in 1887, that operated a broad gauge, 5 ft 6 in (1,676 mm), railway network in the Argentine provinces of San Luis, San Juan and Mendoza. In 1907 it was taken over on a lease by the Buenos Aires and Pacific Railway (BA&P).

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
