Title
General arrangement drawing no 40810
Reference
YA1966.24/3/21/C/21/6843
Production date
1886 - 1886

Creator

Petrie, G. E.Biography Biography
Active c1886-1887, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 6843, which comprised of nine '2-6-0' locomotives for the Costa Rica Railway Progressive numbers 2800-2808
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Costa Rica Railway Biography Biography
Railway company in Costa Rica, known to have been active 1886

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Related object

General arrangement drawing no 40744 Notes Notes

Hierarchy browser

contains 12 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/21 Engineering drawings for orders recorded in Order Book No 26, numbers 6807-6940
- ITEMYA1966.24/3/21/C/21/6843 General arrangement drawing no 40810
