Title
General arrangement drawing no 39090
Reference
YA1966.24/3/21/C/19/6587
Production date
1885 - 1885

Creator

Pearson, G. A.Biography Biography
Active c1885-1887, draughtman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 6587, which comprised of two '0-6-2' tank locomotives for the Wrexham, Mold & Connah's Quay Railway Progressive numbers 2649-2650
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Wrexham, Mold & Connahs Quay Railway Co Biography Biography
Railway incorporated on 7 August 1862 to build a line from Wrexham to Buckley. The company went into receivership in 1897, but continued until the line was bought by the Great Central Railway in 1905.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 7 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/19 Engineering drawings for orders recorded in Order Book No 23, numbers 6561-6683
- ITEMYA1966.24/3/21/C/19/6587 General arrangement drawing no 39090
