Title
General arrangement drawing no 35154
Reference
YA1966.24/3/21/C/17/6371
Production date
1883 - 1883

Creator

Wood, R Biography Biography
Active c1880-1884, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 6371, which comprised of six '2-4-0' tank locomotives for the South Australian Government Railway Progressive numbers 2401-2404 and 2528-2529
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

South Australian Railways Biography Biography
South Australian Railways (SAR) was the statutory corporation through which the Government of South Australia built and operated railways in South Australia from 1854. In March 1978, the non-urban railways were incorporated into Australian National, and the Adelaide urban lines were transferred to the State Transport Authority.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 18 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/17 Engineering drawings for orders recorded in Order Book No 21, numbers 6286-6427
- ITEMYA1966.24/3/21/C/17/6371 General arrangement drawing no 35154
