- TitleGeneral arrangement drawing no 30039
- ReferenceYA1966.24/3/21/C/14/3924
- Production date1880 - 1880
- Scope and ContentGeneral arrangment drawing for order 3924, which comprised of six '2-4-0' locomotives for the Midland Great Western Railway of Ireland Progressive numbers 1960-1965
- Level of descriptionITEM
- Repository nameScience and Industry Museum
- Subject
- Conditions governing accessOpen access.
- Conditions governing ReproductionCopies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
