Title
General arrangement drawing no 29639
Reference
YA1966.24/3/21/C/14/3876
Production date
1880 - 1880

Creator

Fox, -Biography Biography
Active 1898-1906, Draughtsman for Beyer, Peacock & Co. Ltd.

Scope and Content
General arrangement drawing for order 3876, which comprised of two ' 2-4-0' locomotives for the Belfast & Northern Counties Railway Progressive numbers 1921-1922
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Belfast & Northern Counties Railway Biography Biography
Formed in 1848 as the Belfast and Ballymena Railway. The railway became known as the Belfast and Northern Counties Railway (BNCR) in 1860. In 1903, it amalgamated with the Midland Railway, administered by the Northern Counties Committee.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 12 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/14 Engineering drawings for orders recorded in Order Book No 17, numbers 3823-3981
- ITEMYA1966.24/3/21/C/14/3876 General arrangement drawing no 29639
