Title
General arrangement drawing no 28473
Reference
YA1966.24/3/21/C/13/3813
Production date
1879 - 1879

Creator

Shepherd, -Biography Biography
Active c1879-1896, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 3813, which comprised of four '4-4-0' tank locomotives for the South Australian Government Railway Progressive numbers 1883-1886
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

South Australian Railways Biography Biography
South Australian Railways (SAR) was the statutory corporation through which the Government of South Australia built and operated railways in South Australia from 1854. In March 1978, the non-urban railways were incorporated into Australian National, and the Adelaide urban lines were transferred to the State Transport Authority.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
