Title
General arrangement drawing no 27073
Reference
YA1966.24/3/21/C/13/3713
Production date
1878 - 1878

Creator

Smith, W.H.Biography Biography
Active 1873-1880, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 3713, which comprised of three '0-6-4' tank locomotives for the South Australian Government Railway Progressive numbers 1824-1826
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

South Australian Railways Biography Biography
South Australian Railways (SAR) was the statutory corporation through which the Government of South Australia built and operated railways in South Australia from 1854. In March 1978, the non-urban railways were incorporated into Australian National, and the Adelaide urban lines were transferred to the State Transport Authority.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 12 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/13 Engineering drawings for orders recorded in Order Book No 16, numbers 3679-3821
- ITEMYA1966.24/3/21/C/13/3713 General arrangement drawing no 27073
