Title
General arrangement drawing no 20833
Reference
YA1966.24/3/21/C/9/2960
Production date
1873 - 1873

Creator

Smith, W.H.Biography Biography
Active 1873-1880, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 2960, which comprised of two '0-6-0' locomotives for the Great Southern & Western Railway of Ireland Progressive numbers 1251-1252
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Great Southern & Western Railway of Ireland Biography Biography
Irish railway company incorporated in 1844. The first section of the line from Dublin to Cashel was completed and opened in 1846. In 1925 the GS&WR was amalgamated with all the other railways operating wholly within the Irish Free State to form the Great Southern Railways.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 15 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/9 Engineering drawings for orders recorded in Order Book No 11, numbers 2998-3168
- ITEMYA1966.24/3/21/C/9/2960 General arrangement drawing no 20833
