Title
General arrangement drawing no 13000
Reference
YA1966.24/3/21/C/4/2045
Production date
1867 - 1867

Creator

Fox, -Biography Biography
Active 1898-1906, Draughtsman for Beyer, Peacock & Co. Ltd.

Scope and Content
General arrangement drawing for order 2045, which comprised of four '0-6-0' locomotives for the Great Southern & Western Railway of Ireland Progressive numbers 747-750.
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Great Southern & Western Railway of Ireland Biography Biography
Irish railway company incorporated in 1844. The first section of the line from Dublin to Cashel was completed and opened in 1846. In 1925 the GS&WR was amalgamated with all the other railways operating wholly within the Irish Free State to form the Great Southern Railways.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 32 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/4 Engineering drawings for orders recorded in Order Book No 4, numbers 849-2095
- ITEMYA1966.24/3/21/C/4/2045 General arrangement drawing no 13000
