- TitleGeneral arrangement drawing no 11040
- ReferenceYA1966.24/3/21/C/4/850
- Production date1865 - 1865
- Scope and ContentGeneral arrangement drawing for order 850, which comprised of ten '0-6-0' locomotives for the Madras Railway Company (India) Progressive numbers 519-528
- Level of descriptionITEM
- Repository nameScience and Industry Museum
- Subject
- Conditions governing accessOpen access.
- Conditions governing ReproductionCopies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
Creator
Associated people and organisations
Hierarchy browser
- contains 32 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/4 Engineering drawings for orders recorded in Order Book No 4, numbers 849-2095
