- TitleGeneral arrangement drawing no 10479
- ReferenceYA1966.24/3/21/C/4/888
- Production date1864 - 1864
- Scope and ContentGeneral arrangement drawing for tender order 888.
- Level of descriptionITEM
- Repository nameScience and Industry Museum
- Subject
- Conditions governing accessOpen access.
- Conditions governing ReproductionCopies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
Creator
Hierarchy browser
- contains 32 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/4 Engineering drawings for orders recorded in Order Book No 4, numbers 849-2095
