- TitleGeneral arrangement drawing no 3037
- ReferenceYA1966.24/3/21/C/2/268
- Production date1858 - 1858
- Scope and ContentGeneral arrangement drawing for order 268, which comprised of two '0-4-2' locomotives for the Egyptian Government Railway. Progressive numbers 95-96.
- Level of descriptionITEM
- Repository nameScience and Industry Museum
- Subject
- Conditions governing accessOpen access.
- Conditions governing ReproductionCopies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
Creator
Associated people and organisations
Hierarchy browser
- contains 38 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/2 Engineering drawings for orders recorded in Order Book No 2, numbers 259-555
