Title
General arrangement drawing no 1623
Reference
YA1966.24/3/21/C/1/66/4
Production date
1856 - 1856

Creator

Poe, P Biography Biography
Draughtsman for Beyer, Peacock & Co. Ltd, known to have been active 1851-1858

Scope and Content
General arrangement drawing for order 66, which comprised of six '2-2-2' locomotives for Edinburgh & Glasgow Railway. Progressive numbers 21-26.
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Edinburgh & Glasgow Railway Biography Biography
Railway built to link Edinburgh and Glasgow which received its Royal Assent in 1838 and opened in 1842. The line was absorbed into the North British Railway on 1 August 1865.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
