Title
General arrangement proposal drawing no 2
Reference
YA1966.24/3/21/C/1/25/1
Production date
1852 - 1852

Creator

Molyneaux, -Biography Biography
Draughtsman for Beyer, Peacock & Co. Ltd, known to have been active 1855-1870

Scope and Content
General arrangement drawing for order 25, which comprised of ten '2-2-2' locomotives for the East India Railway. Progressive numbers 5-14.
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

East Indian Railway Biography Biography
The East Indian Railway Company subsequently known as the East Indian Railway (EIR) was a pioneering company that introduced rail to Bengal and beyond in eastern India. The company was based in Calcutta. Founded in 1845.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
