Title
General arrangement drawing no 23682
Reference
YA1966.24/3/21/C/11/3370
Production date
1875 - 1875

Creator

Westrhenen, -Biography Biography
Active 1874-1876, draughtsman for Beyer, Peacock & Co. Ltd

Scope and Content
General arrangement drawing for order 3370, which comprised of two '2-4-0' tank locomotives for the Ryde & Newport Railway, Isle of Wight Progressive numbers 1583-1584
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Ryde and Newport Railway Company Biography Biography
Railway company managing the line ran from Smallbrook Junction to Newport, which opened in 1875. In 1887, the company merged with the Cowes and Newport Railway and the Isle of Wight (Newport Junction) Railway to form the Isle of Wight Central Railway (IoWCR)

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 22 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/11 Engineering drawings for orders recorded in Order Book No 13, numbers 3341-3500
- ITEMYA1966.24/3/21/C/11/3370 General arrangement drawing no 23682
