Title
General arrangement drawing no 18108
Reference
YA1966.24/3/21/C/7/2632
Production date
1871 - 1871

Creator

Fox, -Biography Biography
Active 1898-1906, Draughtsman for Beyer, Peacock & Co. Ltd.

Scope and Content
General arrangement drawing for order 2632, which comprised of one '2-4-0' locomotive for the Dublin & Drogheda Railway Progressive number 1042.
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Dublin & Drogheda Railway Biography Biography
Irish railway company. It received royal assent to construct the railway line between Dublin and Drogheda on 13 August 1836. The railway officially opened on 25 May 1844. The company merged with the Dublin and Belfast Junction Railway in 1875 to form the Northern Railway of Ireland.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 18 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/7 Engineering drawings for orders recorded in Order Book No 8, numbers 2573-2771
- ITEMYA1966.24/3/21/C/7/2632 General arrangement drawing no 18108
