- TitleGeneral arrangement drawing no 8116
- ReferenceYA1966.24/3/21/C/3/630
- Production date1862 - 1862
- Scope and ContentGeneral arrangement drawing for tender order 630
- Level of descriptionITEM
- Repository nameScience and Industry Museum
- Subject
- Conditions governing accessOpen access.
- Conditions governing ReproductionCopies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.
Creator
Associated people and organisations
Related object
Hierarchy browser
- contains 36 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/3 Engineering drawings for orders recorded in Order Book No 3, numbers 556-848
