Title
General arrangement drawing no 2777
Reference
YA1966.24/3/21/C/1/225
Production date
1857 - 1857

Creator

Jaeger, -Biography Biography
Draughtsman for Beyer, Peacock & Co. Ltd, known to have been active 1855-1859

Scope and Content
General arrangement drawing for order 225, which comprised of two '0-4-2' locomotives for Dublin & Drogheda Railway. Progressive numbers 75-76.
Level of description
ITEM
Repository name
Science and Industry Museum

Associated people and organisations

Dublin & Drogheda Railway Biography Biography
Irish railway company. It received royal assent to construct the railway line between Dublin and Drogheda on 13 August 1836. The railway officially opened on 25 May 1844. The company merged with the Dublin and Belfast Junction Railway in 1875 to form the Northern Railway of Ireland.

Subject
Railway transport
Railroad locomotive industry
large format document
Conditions governing access
Open access.
Conditions governing Reproduction
Copies may be supplied in accordance with current copyright legislation and Science Museum Group terms and conditions.

Hierarchy browser

contains 27 partsSUB-SUB-SUB-SERIESYA1966.24/3/21/C/1 Engineering drawings for orders recorded in Order Book No 1, numbers 1-258
- ITEMYA1966.24/3/21/C/1/225 General arrangement drawing no 2777
